This liquid filling & capping machine is new generation utility product, which is best suitable ofr needle-insert filling in the small opening mouth of bottle less than 3.0mm. It can automatically accomplish bottle in-feeding, filling, cap placing, and screw capping. Vacuum suck system is specially used to accumulate the rudimental oil attached outside surface of bottle and nozzles, avoid the oil overflowing onto the surface of bottle to gog against label stick. This machine is design and produce accordance with regulation.
Main technical parameter
u Filling range:2-20ml
u Filling precision:≤±2%
u Capacity: single station:30-40bpm rotary multiple stations:60-80bpm
u Qualified capping:≥99%
u Rated power:1.0Kw
u Power supply:220V 50Hz
u Net weight:500Kg
u Overall dimension:1800*850*1600(mm)
